Condition:
  New
Part Number:
  P107318
Warranty:
  1-Year Limited Warranty

Available Now:
4  



$12,214.76


Regular Price: $14,370.31

On Sale Flyer
Print Version

Pfeiffer HiCube 80 Eco Benchtop Turbomolecular Pump Station KF40 inlet, MVP 015-2, with XMPT 200 AR Gauge and Cable


Pfeiffer HiCube™ 80 Eco Benchtop Turbomolecular Pump Station KF40 NW40 Inlet with Cold Cathode Pirani X MPT 200 AR Vacuum Gauge (KF25 inlet) and Cable.

This Pfeiffer HiCube 80 Eco is the complete solution for high vacuum applications. It is modular, flexible, compact and versatile. Comes with a HiPace 80 Turbo Pump with fan cooling included and a KF40 NW40 inlet flange, MVP 015-2 Diaphragm (Backing/Roughing Pump), TPS 110 Power Supply Pack and a DCU 002 (Display and Control Unit). This Pfeiffer HiPace 80 ECO pumping station also comes with a XPT 200 AR (Analog Relay) Pressure Gauge with Set Points, and KF25 inlet). This Gauge is the "X" PT MPT 200 with analog relay and set points. (not the standard version MPT 200 gauge which has no analog relays or set points). The extra (8-pin, A-coded) connector on the gauge with the text "analog/relay" can be used to connect to an ActiveLine controller and to evaluate the switching contacts. The analog signal and relay contacts can also be evaluated using customer-specific circuitry.

The DCU 002 can also be removed from the metal case and used as a remote control. This pumping station will pump down to 10-8 Torr and the XMPT 200 AR Cold Cathode Pirani Gauge will read to 3.75 X 10-9. This unit is completely plug and play and easily integrates well with other Pfeiffer Vacuum Gauges. A power cable is NOT supplied with this unit. For complete instruction manuals on the HiCube 80 Eco pumping station and X MPT 200 AR gauge, scroll down to (AVAILABLE DOWNLOADS) below and download the PDF's.




Press ESC to Close


PDF Logo Pfeiffer HiCube 80 ECO Turbo Pumping Station Operating Instructions.pdf

PDF Logo Pfeiffer MPT 200 Digital Pirani/Cold Cathode Gauge Operating Instructions.pdf

PDF Logo Pfeiffer XPT 200AR DigiLine Gauge Supplementary Information to Operating Instructions.PDF
