Home > Vacuum Pumps > Turbo Pumps And Controllers > Turbo Pumps > Edwards > nEXT1230H Turbopumps > Edwards Dual Fan Radial Air Cooling Unit for nEXT 1230H Turbo Pump, PN: B8J200801

Condition:

New

Part Number:

P1013475

Warranty:

Against Product Defect

Available Now: 2

$1,408.27

Print Version

Edwards Dual Fan Radial Air Cooling Unit for nEXT 1230H Turbo Pump, PN: B8J200801

Edwards Dual Fan Radial Air Cooling Unit for nEXT 1230H Turbo Pumps.
Edwards Part Number: B8J200801.

This Edwards radial air cooling dual fan unit fits the nEXT1230H turbo pump and provides air flow perpendicular to the pump. The air cooling facility is powered via the pump's auxilliary connector and will always run when the pump is on. This radial air cooling unit can be used in combination with the EPS 800 power supply mounted to the pump's side (mounting kit part number P1012528 is required). The power supply mounting kit is not required when the power supply is used remotely from the pump. This Edwards radial air cooling unit includes mounting screws and has part number B8J200801.

This dual fan radial air cooling kit can be used on these pumps:

nEXT1230H

Press ESC to Close

Edwards nEXT 730D 930D Turbo Pump Air Cooler Manual.pdf

Edwards nEXT 730D 930D 1230H Turbo Pumps Instruction Manual.pdf

Edwards nEXT 730D 930D 1230H Turbo Pump Datasheet.pdf

Edwards nEXT Turbomolecular Pumps Entire Range Brochure.pdf

Edwards EPS 800 Power Supply for nEXT 730D 930D 1230H Turbo Pumps Instruction Manual.pdf

P1013475.sldprt

P1013475.step

Ideal Spectroscopy offers 3D CAD models in Solidworks (SLDPRT), STP, & STEP formats. For those without CAD software a free trial 3D model viewer with measurement capabilities can be downloaded here:

eDrawings Viewer For Windows
eDrawings Viewer For MAC.
