New Edwards ITO20K Vacuum Inlet CATCHPOT with KF25 flanges , Part Number A441-10-000
NEW Edwards ITO20K Inlet CATCHPOT - KF25 (Edwards Part Number A441-10-000)
The Edwards ITO20K Inlet CATCHPOT Provides the following benefits:
The ITO Inlet Catchpot is used on vacuum processes where large quantities of vapour
are produced. The catchpot traps liquid that would otherwise condense in the
pipelines and drain towards the pump. The catchpot is also suitable for use on
vacuum processes where froth or spray can go into the pump.
The mixture of gas and liquid droplets enters the inlet of the catchpot. The liquid collects in the base of the body and the
gas passes through the outlet into the pump.
You can see the level of the trapped liquid through the sight-glass. You can drain
the trapped liquid from the catchpot through the drain-plug. NOTE: The CATCHPOT DOES NOT have the media trapping material like the ITC Chemical Trap. For complete manual see .pdf to the side at Downloads.
Fit & Size:
Fits Edwards RV3, RV5, RV8, RV12, E2M2, E2M5, E2M8, E2M12, E1M18, E2M18, E2M28 and E2M30 Rotary Vane Oil Sealed Vacuum Pumps.
KF25 inlet, KF25 outlet.
Weight 3.5 kg.
Edwards Part Number A44110000
