Sodium Chloride (NaCl) Replacement Window for Glass Vacuum Gas Cell, 1.5" OD, 0.23" Thickness.

Sodium Chloride (NaCl) Replacement Window for Glass Vacuum Gas Cell, 1.5" (38.1 mm) OD, 0.236" (6 mm) Thickness.

This listing is for the sale of one (1) replacement window for an Ideal Vacuum Glass Vacuum Gas Cell with the following characteristics:

Material: Sodium Chloride (NaCl).
Dimensions: 1.5" (38.1 mm) OD, 0.236" (6 mm) Thickness.
Flat, No Wedge.

Sodium Chloride (NaCl) Properties

Optical

Transmission Range: 0.2 to 15 µm

Refractive Index: 1.49 at 10.6 µm

Reflection Loss: 7.5% at 10.6 µm

Absorption Coef.: 7.0 x 10^-6 cm^-1 at 10.6 µm

Reststrahlen Peak: 50.1 µm

Chemical behavior of polished surfaces

Climatic resistance class CR (n/a) (ISO/WD 13384)

Acid resistance class SR (n/a) (ISO 8424)

Alkali resistance class AR (n/a) (ISO 10629)

Phosphate resistance class PR (n/a) (ISO 9689)

Stain resistance class FR (n/a)

Solubility: 35.7g/100g water at 20°C (Do NOT immerse in water.)

Press ESC to Close

P1012260.sldprt

P1012260.step

Ideal Spectroscopy offers 3D CAD models in Solidworks (SLDPRT), STP, & STEP formats. For those without CAD software a free trial 3D model viewer with measurement capabilities can be downloaded here:

eDrawings Viewer For Windows
eDrawings Viewer For MAC.
