Brooks CTI Cryo-Torr CT-8F Cryopump 15K Charcoal Array.
15K Charcoal Array Only
This is a replacement 15k Charcoal Array for a CTI Cryo-Torr CT-8F cryo pump.
The CTI-Cryogenics Cryo-Torr CT-8F pumps, are one of the two
major components that make up the Cryo-Torr Pumping System. The
second component is the Compressor (also sold on this website).
The Cryo-Torr CT-8F Cryopump, provides fast, clean pumping of all gases in the 10-3 to 10-9 Torr range. Standard applications include, Semiconductor, Aerospace & Vacuum coating as well as R&D.
The cryo-pump operates on the principle that gases can be condensed and held at extremely low vapor pressures, achieving high speeds and through puts. This pump is a highly-reliable and rugged unit that requires minimal servicing. Since the cryo-pump exposes no moving parts, operating fluids, or backing pumps to the vacuum, the possibility of system or process contamination from the cryo-pump itself is eliminated.
Descripition, Installation, Regeneration, and Maintenance Procedures are covered in the .pdf at the downloads section to the side.
