Thermo Scientific Lindberg/Blue M Heavy-Duty 1200°C Box Furnace, Single Heating zones (100°C to 1,200°C), Digital Programable Controller with Over Temperature Control and Factory Installed RS-485 Digital Communications Port, 208/240V, 50/60 Hz, 30A, for use with the HTF55322C (P1013923) or HTF55342C (P1013924) Tube Furnaces.
Thermo Scientific Part Number: CC58114PBCOMC-1.
Thermo Scientific™ Lindberg/Blue M™ Heavy-Duty 1200°C Box furnace controller for increased temperature accuracy, 5 programs with 16 segments each, 208/240 V, 50/60 Hz, 30 A, Features overtemperature control and multiple segment configuration; designed to work with the 1200°C split-hinge and 1500°C box furnaces.
Key Features
- Fully wired with advanced microprocessor-based digital control, solid-state power module, on/off curcuit breaker and thermocouple input jacks for each zone
- Built-in adjustable high-limit overtemperature protection
- LED simultaneously displays actual temperature vs. setpoint in °C or °F
- Designed for operation on 120, 208, or 240V 50/60Hz, single-phase line
Overtemperature Control
- Adjustable digital control is factory installed
- Protects furnace and load in the event of primary control curcuit failure
- Center zone uniformity achieved and operating length maximized through adjustable profiling of end zones by independent controller
- Overrides main controller and shuts off power to furnace if high limit is reached
- Must be manually reset for safety
- Operates via magnetic contacts through a signal from an independent thermocouple
1200°C Digital, Single Setpoint Controllers for Split-hinge Furnaces (CC58114PBA, CC58114PA)
- Includes one microprocessor-based PID control, single segment, single setpoint, one ramp to setpoint
- CC58114PBA includes overtemperature control
