Rotatable Bolt Ring Adapter for non bolted NW-200 Vacuum Fittings, ISO-LF Large Flange Size NW-200, 12 bolt holes, Mild Steel Each Kit includes one flange, a retaining-ring and screws, nuts and washers to fit the rotatable flange to another
rotatable flange.
These rotatable bolt ring adapters are for making non bolted ISO-K collar flanges into ISO-F smooth bolt hole flanges. Standard ISO LF NW Centering Rings can be used. (see far right graphic above). The NW-200 ISO-KF 200 flange has 12 bolt holes. They follow International Standards Organization (ISO) standards and have a flange size of NW-200. ISO flanged vacuum fittings are commonly used to build process vacuum plumbing and systems for industrial applications. The fittings are quick to assemble using double claw clamps or bolts and a centering ring.
Rotatable Bolt Ring, NW-200 Vacuum Fittings, ISO-LF Large Flange Size NW-200, Aluminum
ISO-LF Flange Size: NW-200 with twelve bolt holes.
Material: Mild Steel retaining ring.
