Condition:
  New
Part Number:
  P102910
Warranty:
  Leybold Warranty

Available Now:
1  



$3,120.57


Print Version

Leybold ARS 16-25 Exhaust Filter w/ Lubricant Return, for Leybold D 16BCS, D 25BCS, P/N 18956


NEW Leybold ARS 16-25 Exhaust Filter w/ Lubricant Return, for Leybold D16BCS, D25BCS, Leybold P/N 18956

This combination of an exhaust filter with a float controlled valve considerably extends the manintenance intervals of the TRIVAC BCS. The typical application is for filtering the exhaust air of entrapped lubricant particles. This ARS exhaust filter is connected to the exhaust port of the TRIVAC BCS, the return line is connected at the intermediate flange under the intake port. Supplied Equipment includes intermediate flange, connecting lines with hollow screws, required gaskets as well as mounting screws for the intake flange. Can be used with hydrocarbon or PFPE oil systems. For complete specifications and advantages to the user, download data sheet see below. (AVAILABLE DOWNLOADS:)

Leybold Filter with Lubricant Return ARS 16-25:
Fits Pump Models: Leybold D16B, D16BCS, Leybold D25B, D25BCS
Inlet & Exhaust Flanges: ISO KF25 (NW25)
Weight: 10.4 lb
Replacement Filter Element FE 16-25: Leybold Part No. 18972


Press ESC to Close


PDF Logo Leybold ARS 16-25, 40-65 Exhaust Filter Operating Instructions.pdf

PDF Logo Leybold ARS 16-25, ARS 40-65 Exhaust Filter Parts Lis & Exploded View.pdf

PDF Logo Leybold ARS 16-25, 40-65 Exhaust Filters with Lubricant Return Data Sheet.pdf

PDF Logo IVP Technical Considerations for Selecting Vacuum Components for Chemical Processes.pdf
