Home > ISO-F DN 400 Bolt Set, for Ideal Vacuum UltraLock Gate Valves Tapped Holes, Metric M12 x 50 mm Long Bolts, 1.75 mm Pitch, Silver-Plated, Quantity of 16

Condition:

New

Part Number:

P1013160

Warranty:

Against Product Defect

Available Now: 5

RoHS Compliance Sticker

$42.36

Print Version

ISO-F DN 400 Bolt Set, for Ideal Vacuum UltraLock Gate Valves Tapped Holes, Metric M12 x 50 mm Long Bolts, 1.75 mm Pitch, Silver-Plated, Quantity of 16

ISO-F DN 400 Bolt Set, for Ideal Vacuum UltraLock Gate Valves Tapped Holes, Metric M12 x 50 mm Long Bolts, 1.75 mm Pitch, Silver-Plated, Quantity of 16 bolts washers included.

These bolts are for tapped threaded hole flanges and follow ISO-LF standards for flange size NW-400. ISO flanged vacuum fittings are commonly used to build process vacuum plumbing and systems for industrial applications. The fittings are quick to assemble using double claw clamps and a centering ring (please see top right figure - click to enlarge). The Viton® centering ring contains a rubber/elastomeric o-ring. The ISO standard sizes for large flanges are NW-63, NW-80, NW-100, NW-160, NW-200, NW-250, NW-320, NW-400, NW-500, NW-630. These vacuum fittings are made of corrosive resistant stainless steel.

Bolts, for Tapped Threaded Hole NW-400, Vacuum Flanges, Silver-Plated, Quantity of 16
ISO-LF Flange Size: NW-400
Quantity: 16 bolts include washers
Common Dimensions: Bolt Size M12 x 50 x 1.75mm Pitch

Press ESC to Close

Availability Of Kit Components Kit: P1013160 - ISO-F DN 400 Bolt Set, for Ideal Vacuum UltraLock Gate Valves Tapped Holes, Metric M12 x 50 mm Long Bolts, 1.75 mm Pitch, Silver-Plated, Quantity of 16
Component	Desc.	Req'd	Avail
Non-Standard	No Component Description Available On Website	16	1144
Non-Standard	No Component Description Available On Website	16	92

RoHS Compliance Download
