Home > > > Adaptive Reducing Tee ISO-160 to KF25, ISO MF Interface, LF160 to KF25, Stainless Steel

Condition:

New

Part Number:

P108093

Warranty:

Against Product Defect

Available Now: 2

RoHS Compliance Sticker

$952.35

Print Version

Adaptive Reducing Tee ISO-160 to KF25, ISO MF Interface, LF160 to KF25, Stainless Steel

Custom Manufactured ISO-160 to KF-25 Adaptive Reducing Tee, 304 Stainless Steel, GTAW fusion welded.

These ISO-160 to KF-25 Adaptive Reducer Tee vacuum fittings follow ISO-KF and LF standards and have a flange size of LF160 to NW-25, made of corrosive resistant 304 stainless steel. Assembled and helium leak tested at 7x10-9 atm cc/second. They are commonly used to build vacuum plumbing and process systems. We make many other custom fittings for your vacuum needs.

Reducer Tee ISO 160 to KF-25
ISO-KF Flange Cross Size: ISO LF-160 to NW-25

Common Dimensions:
Flange 1 & 2 LF ISO 160
Flange 3 KF25 NW25
A= 2.08 in. (52.8mm)
B= 3.54 in. (89.9mm)

Press ESC to Close

RoHS Compliance Download

P108093.sldprt

P108093.step

Ideal Spectroscopy offers 3D CAD models in Solidworks (SLDPRT), STP, & STEP formats. For those without CAD software a free trial 3D model viewer with measurement capabilities can be downloaded here:

eDrawings Viewer For Windows
eDrawings Viewer For MAC.
