Isotopic Rubidium 85 Reference Cell, 85Rb, 19 mm Diameter, 75 mm Length


Rubidium 85 (85Rb) Reference Cell.

These flame-sealed cells contain a small amount of solid, >98% chemically pure, isotopically pure rubidium 85 (85Rb) under vacuum. The concentration of rubidium in the vapor phase may be controlled by heating the cell or cooling the tipoff stem. Operating temperatures typically range from 20-80°C. Rubidium has intermitant strong absorption lines which are used for calibration of tunable lasers and wavelength meters in the range of 6540-48300 cm-1 (207-1529 nm). They may also be used to stabilize laser frequencies via locking to a single strong absorption line.

The quartz cell body is cylindrical in shape; outer diameter 19 mm; length 75 mm. The tipoff stem is centered on the cell, protruding not more than 10 mm from the cell body. Windows are angled 11° off of normal and have a 2° interior wedge to prevent back-reflection and etalon effects.



Press ESC to Close


PDF Logo RoHS Compliance Download

PDF Logo Ideal Vacuum Company Overview Brochure.pdf

Ideal Spectroscopy offers 3D CAD models in Solidworks (SLDPRT), STP, & STEP formats. For those without CAD software a free trial 3D model viewer with measurement capabilities can be downloaded here:

E-drawing LogoeDrawings Viewer For Windows
E-drawing LogoeDrawings Viewer For MAC.
