Hamamatsu Photomultiplier Tube R955 28mm Diameter Photocathode, 9-Stage, Side-On, 250µA/lm


Hamamatsu Photomultiplier Tube: R955 28mm Diameter Photocathode, 9-Stage, Side-On, Cathode Luminous Sensitivity: 250µA/lm

Photomultiplier tubes (PMT) are extremely sensitive light detectors which amplify the current produced by incident light, allowing individual photons to be registered and observed. PMT's are used in a variety of applications which require ultra-sensitive photometric capabilities such as:
  • Biomedical Analysis: Florescence Immuno Assy, Flow Cytometer, MTP Reader
  • Environmental Monitoring: NOx Analyzer
  • Spectroscopy: UV-VIS Spectrometer, Fluorescence Spectrometer, Atomic Absorption, Raman Spectrometer
  • Semiconductor Industry: Wafer Inspection, Particle Counter
These R955 PMT's are side-on photomultiplier tubes, using a circular-cage type electron multiplier which has the benefits of compactness and fast response time. Side-on PMT's often demonstrate higher quantum efficiencies than head-on (end-on) PMT's having photocathodes of similar composition. Typical head on PMT's use a Box and Grid type dynode setup and can experience slow response time in some applications. Side-on PMT's are relatively low cost compared to head-on and are standard in photometrics. These R955 PMT's have a Spectral Response of 160 to 900nm and a Quantum Efficiency of 29% at 260nm. A complete specifiaction manual is at downloads to the side.


Press ESC to Close


Hamamatsu Photomultiplier Tubes R955
PDF Logo RoHS Compliance Download

PDF Logo Hamamatsu Photomultiplier Tubes Basics and Applications.pdf

PDF Logo Hamamatsu PMT Power Supply C7169_Datasheet.pdf
