MKS Granville Phillips 475 Convectron Gauge Kit, with 275 Convectron Gauge 4 VCR 1/4 in., 2 Set Points

This is a complete plug and play vacuum measurement package kit. It contains the MKS Granville Phillips Series 475 Convectron Controller with its easy to use larger and brighter, highly visible Vacuum Florescent Display (VFD) and intuitive front panel controls that allow gauge calibration and adjustment of vacuum measurement parameters without the need for special tools. This Series 475 Convectron Controller provides a range of control I/O and several new features such as self diagnostics, integrated Convectron Gauge simulation, built-in gas curves and is RoHS/CE compliant. This provides ease of use, better system control, and increased productivity.

In total this kit includes an MKS Granville Phillips 475 pressure gauge controller, 1/8 inch DIN, panel mount with digital display configured to display measurements in Torr, 2 set points. The kits also includes the 10 ft. sensor cable, 1-Phase 115 VAC power supply and MKS 275 gauge sensor with 4 VCR 1/4 in. vacuum connection. These MKS Granville Phillips 475 pressure gauge kits can measure pressure from Atmosphere to 1x10-4 Torr. This is a complete pressure gauge kit to connect and measure pressure on a 4 VCR 1/4 in. vacuum fitting.

Availability Of Kit Components Kit: P107617 - MKS Granville Phillips 475 Convectron Gauge Kit, with 275 Convectron Gauge 4 VCR 1/4 in., 2 Set Points
Component	Desc.	Req'd	Avail
Non-Standard	No Component Description Available On Website	1	23
P102686	MKS Granville Phillips 275 Convectron Gauge Vacuum Pressure Measurement Sensor, 4 VCR 1/4 inch. PN: 275185	1	67
P103970	MKS Granville Phillips 475 Convectron Vacuum Pressure Gauge Controller with 2 set points PN: 475001-A2-T	1	14
P104111	MKS Granville Phillips 475 Convectron Gauge Controller Signal Cable 3m (10 ft.) PN: 475012-10	1	41
