Leybold TURBOLAB Core 90i, Conflat CF 4.5 Inch Inlet Flange, 90 l/s Pumping Speed, Ultimate Pressure 3.75x10-10 Torr, DIVAC 1.4 Backing Pump, KF-16 Exhaust Flange, 1-Phase 110/230 VAC. Leybold PN 501591V01000500.
Out of Stock


The Leybold TURBOLAB Core 90i is a cost-efficient easy to use bench top vacuum pumping station that comes with Conflat CF 4.5 inch inlet and KF-16 exhaust flanges. The overall pumping speed for nitrogen is 90 liters/sec and reaches an ultimate pressure of 3.75x10-10 Torr (5x10-10 mBar), making it a true ultra-high vacuum (UHV) pumping system. The Turbolab Core 90i includes a TURBOVAC 90i pump and a DIVAC 1.4 oil-free backing pump that helps fulfill all expectations in terms of reliability, simplicity, and precision. The system operates on either 1-phase 110 or 230 VAC and has Leybold part number 501591V01000500. They are one of the simplest high-vacuum system to use; as they have a single start/stop button for the entire pumping station. This innovative design incorporates a turbomolecular pump and a backing pump together with a simple controller, all 3 fitted on a robust baseplate, making it the ideal solution for many applications. With its one-gauge connection the TURBOLAB Core pumping station can be operated with either a TTR 91RN, TTR 101, PTR 90N, or PTR 225N vacuum gauge. Additionally, you can connect a venting valve with the turbomolecular pump. With the option gauge fitted, the controller can display gauge pressure or turbopump speed.

Condition: New



Product Number: P1013227



Price: $6,891.75


*Regular Price: $9,189.00



Leybold TURBOLAB Core 250i, ISO 100 K Inlet Flange, 250 l/s Pumping Speed, Ultimate Pressure 6x10-8 Torr, DIVAC 1.4 Backing Pump, KF-16 Exhaust Flange, 1-Phase 110/230 VAC, Leybold PN 501591V08000500.
In Stock: 1


Torr, DIVAC 1.4 Backing Pump. The Leybold TURBOLAB Core 250i is a cost-efficient easy to use bench top vacuum pumping station that comes with ISO 100 K inlet and KF-16 exhaust flanges. The overall pumping speed for nitrogen is 250 liters/sec and reaches an ultimate pressure of 6x10 Torr (8x10 mBar). The Turbolab Core 250i includes a TURBOVAC 250i pump and a DIVAC 1.4 oil-free backing pump that helps fulfill all expectations in terms of reliability, simplicity, and precision. The system operates on either 1-phase 110 or 230 VAC and has Leybold part number 501591V08000500. They are one of the simplest high-vacuum system to use; as they have a single start/stop button for the entire pumping station. This innovative design incorporates a turbomolecular pump and a backing pump together with a simple controller, all 3 fitted on a robust baseplate, making it the ideal solution for many applications. With its one-gauge connection the TURBOLAB Core pumping station can be operated with either a TTR 91RN, TTR 101, PTR 90N, or PTR 225N vacuum gauge. Additionally, you can connect a venting valve with the turbomolecular pump. With the option gauge fitted, the controller can display gauge pressure or turbopump speed.

Condition: New



Product Number: P1013234



Price: $9,476.25


*Regular Price: $12,635.00



Leybold TURBOLAB 90i, Conflat CF 4.5 Inch Inlet Flange, 90 l/s Pumping Speed, Ultimate Pressure 3.75x10-10 Torr, DIVAC 3.0 Backing Pump, KF-16 Exhaust Flange, 1-Phase 110/230 VAC. Leybold PN 501592V01001000.
In Stock: 4


Torr, DIVAC 3.0 Backing Pump. The Leybold TURBOLAB 90i is a cost-efficient easy to use bench top vacuum pumping station that comes with Conflat CF 4.5 inch inlet and KF-16 exhaust flanges. The overall pumping speed for nitrogen is 90 liters/sec and reaches an ultimate pressure of 3.75x10 Torr (5x10 mBar), making it a true ultra-high vacuum (UHV) pumping system. The Turbolab 90i includes a TURBOVAC 90i pump and the large DIVAC 3.0 oil-free backing pump that helps fulfill all expectations in terms of reliability, simplicity, and precision. The system operates on either 1-phase 110 or 230 VAC and has Leybold part number 501592V01001000. They are one of the simplest high-vacuum system to use; as they have a single start/stop button for the entire pumping station. This innovative design incorporates a turbomolecular pump and a backing pump together with a simple controller, all 3 fitted on a robust baseplate, making it the ideal solution for many applications. With its one-gauge connection the TURBOLAB pumping station can be operated with either a TTR 91RN, TTR 101, PTR 90N, or PTR 225N vacuum gauge. Additionally, you can connect a venting valve with the turbomolecular pump. With the option gauge fitted, the controller can display gauge pressure or turbopump speed.

Condition: New



Product Number: P1013224



Price: $9,453.00


*Regular Price: $12,604.00



Leybold TURBOLAB Core 90i, KF-40 Inlet Flange, 90 l/s Pumping Speed, Ultimate Pressure 6x10-8 Torr, DIVAC 1.4 Backing Pump, KF-16 Exhaust Flange, 1-Phase 110/230 VAC, Leybold PN 501591V02000500.
Out of Stock


The Leybold TURBOLAB Core 90i is a cost-efficient easy to use bench top vacuum pumping station that comes with KF-40 inlet and KF-16 exhaust flanges. The overall pumping speed for nitrogen is 90 liters/sec and reaches an ultimate pressure of 6x10-8 Torr (8x10-8 mBar). The Turbolab Core 90i includes a TURBOVAC 90i pump and a DIVAC 1.4 oil-free backing pump that helps fulfill all expectations in terms of reliability, simplicity, and precision. The system operates on either 1-phase 110 or 230 VAC and has Leybold part number 501591V02000500. They are one of the simplest high-vacuum system to use; as they have a single start/stop button for the entire pumping station. This innovative design incorporates a turbomolecular pump and a backing pump together with a simple controller, all 3 fitted on a robust baseplate, making it the ideal solution for many applications. With its one-gauge connection the TURBOLAB Core pumping station can be operated with either a TTR 91RN, TTR 101, PTR 90N, or PTR 225N vacuum gauge. Additionally, you can connect a venting valve with the turbomolecular pump. With the option gauge fitted, the controller can display gauge pressure or turbopump speed.

Condition: New



Product Number: P1013228



Price: $6,682.50


*Regular Price: $8,910.00



Leybold TURBOLAB 250i, ISO-100 Inlet Flange, 250 l/s Pumping Speed, Ultimate Pressure 6x10-8 Torr, DIVAC 3.0 Backing Pump, KF-16 Exhaust Flange, 1-Phase 110/230 VAC, Leybold PN 501592V08001000.
In Stock: 2


Torr, DIVAC 3.0 Backing Pump. The Leybold TURBOLAB 250i is a cost-efficient easy to use bench top vacuum pumping station that comes with ISO-100 inlet and KF-16 exhaust flanges. The overall pumping speed for nitrogen is 90 liters/sec and reaches an ultimate pressure of 6x10 Torr (8x10 mBar). The Turbolab 250i includes a TURBOVAC 250i pump and a DIVAC 3.0 oil-free backing pump that helps fulfill all expectations in terms of reliability, simplicity, and precision. The system operates on either 1-phase 110 or 230 VAC and has Leybold part number 501592V08001000. They are one of the simplest high-vacuum system to use; as they have a single start/stop button for the entire pumping station. This innovative design incorporates a turbomolecular pump and a backing pump together with a simple controller, all 3 fitted on a robust baseplate, making it the ideal solution for many applications. With its one-gauge connection the TURBOLAB pumping station can be operated with either a TTR 91RN, TTR 101, PTR 90N, or PTR 225N vacuum gauge. Additionally, you can connect a venting valve with the turbomolecular pump. With the option gauge fitted, the controller can display gauge pressure or turbopump speed.

Condition: New



Product Number: P1013232



Price: $10,590.00


*Regular Price: $14,120.00



Leybold TURBOLAB Core 90i, ISO 63 K Inlet Flange, 90 l/s Pumping Speed, Ultimate Pressure 6x10-8 Torr, DIVAC 1.4 Backing Pump, KF-16 Exhaust Flange, 1-Phase 110/230 VAC, Leybold PN 501591V00000500.
Out of Stock


The Leybold TURBOLAB Core 90i is a cost-efficient easy to use bench top vacuum pumping station that comes with ISO 63 K inlet and KF-16 exhaust flanges. The overall pumping speed for nitrogen is 90 liters/sec and reaches an ultimate pressure of 6x10-8 Torr (8x10-8 mBar). The Turbolab Core 90i includes a TURBOVAC 90i pump and a DIVAC 1.4 oil-free backing pump that helps fulfill all expectations in terms of reliability, simplicity, and precision. The system operates on either 1-phase 110 or 230 VAC and has Leybold part number 501591V00000500. They are one of the simplest high-vacuum system to use; as they have a single start/stop button for the entire pumping station. This innovative design incorporates a turbomolecular pump and a backing pump together with a simple controller, all 3 fitted on a robust baseplate, making it the ideal solution for many applications. With its one-gauge connection the TURBOLAB Core pumping station can be operated with either a TTR 91RN, TTR 101, PTR 90N, or PTR 225N vacuum gauge. Additionally, you can connect a venting valve with the turbomolecular pump. With the option gauge fitted, the controller can display gauge pressure or turbopump speed.

Condition: New



Product Number: P1013225



Price: $6,633.00


*Regular Price: $8,844.00



Leybold TURBOLAB Core 250i, Conflat CF 6.0 Inch Inlet Flange, 250 l/s Pumping Speed, Ultimate Pressure 3.75x10-10 Torr, DIVAC 1.4 Backing Pump, KF-16 Exhaust Flange, 1-Phase 110/230 VAC. Leybold PN 501591V09000500.
Out of Stock
Expecting: 1
Arrival: 1 on 2024-12-13


Torr, DIVAC 1.4 Backing Pump. The Leybold TURBOLAB Core 250i is a cost-efficient easy to use bench top vacuum pumping station that comes with Conflat CF 6.0 inch inlet and KF-16 exhaust flanges. The overall pumping speed for nitrogen is 250 liters/sec and reaches an ultimate pressure of 3.75x10Torr (5x10 mBar), making it a true ultra-high vacuum (UHV) pumping system. The Turbolab Core 250i includes a TURBOVAC 250i pump and a DIVAC 1.4 oil-free backing pump that helps fulfill all expectations in terms of reliability, simplicity, and precision. The system operates on either 1-phase 110 or 230 VAC and has Leybold part number 501591V09000500. They are one of the simplest high-vacuum system to use; as they have a single start/stop button for the entire pumping station. This innovative design incorporates a turbomolecular pump and a backing pump together with a simple controller, all 3 fitted on a robust baseplate, making it the ideal solution for many applications. With its one-gauge connection the TURBOLAB Core pumping station can be operated with either a TTR 91RN, TTR 101, PTR 90N, or PTR 225N vacuum gauge. Additionally, you can connect a venting valve with the turbomolecular pump. With the option gauge fitted, the controller can display gauge pressure or turbopump speed.

Condition: New



Product Number: P1013235



Price: $9,981.75


*Regular Price: $13,309.00



Leybold TURBOLAB 90i, ISO 63 K Inlet Flange, 90 liters/sec Pumping Speed, Ultimate Pressure of 6x10-8 Torr, DIVAC 3.0 Backing Pump, 1-Phase 110/230 VAC, KF-16 Exhaust Flange, Leybold PN 501592V00001000.
In Stock: 2


Torr, DIVAC 3.0 Backing Pump. The Leybold TURBOLAB 90i is a cost-efficient easy to use bench top vacuum pumping station that comes with ISO 63 K inlet and KF-16 exhaust flanges. The overall pumping speed for nitrogen is 90 liters/sec and reaches an ultimate pressure of 6x10 Torr (8x10 mBar). The Turbolab 90i includes a TURBOVAC 90i pump and the large DIVAC 3.0 oil-free backing pump that helps fulfill all expectations in terms of reliability, simplicity, and precision. The system operates on either 1-phase 110 or 230 VAC and has Leybold part number 501592V00001000. They are one of the simplest high-vacuum system to use; as they have a single start/stop button for the entire pumping station. This innovative design incorporates a turbomolecular pump and a backing pump together with a simple controller, all 3 fitted on a robust baseplate, making it the ideal solution for many applications. With its one-gauge connection the TURBOLAB pumping station can be operated with either a TTR 91RN, TTR 101, PTR 90N, or PTR 225N vacuum gauge. Additionally, you can connect a venting valve with the turbomolecular pump. With the option gauge fitted, the controller can display gauge pressure or turbopump speed.

Condition: New



Product Number: P1013222



Price: $9,195.00


*Regular Price: $12,260.00



Leybold TURBOLAB 250i, Conflat CF 4.5 Inch Inlet Flange, 250 l/s Pumping Speed, Ultimate Pressure 3.75x10-10 Torr, DIVAC 3.0 Backing Pump, KF-16 Exhaust Flange, 1-Phase 110/230 VAC. Leybold PN 501592V09001000.
In Stock: 1


The Leybold TURBOLAB 250i is a cost-efficient easy to use bench top vacuum pumping station that comes with Conflat CF 6.0 inch inlet and KF-16 exhaust flanges. The overall pumping speed for nitrogen is 90 liters/sec and reaches an ultimate pressure of 3.75x10 Torr (5x10 mBar), making it a true ultra-high vacuum (UHV) pumping system. The Turbolab 90i includes a TURBOVAC 250i pump and the large DIVAC 3.0 oil-free backing pump that helps fulfill all expectations in terms of reliability, simplicity, and precision. The system operates on either 1-phase 110 or 230 VAC and has Leybold part number 501592V09001000. They are one of the simplest high-vacuum system to use; as they have a single start/stop button for the entire pumping station. This innovative design incorporates a turbomolecular pump and a backing pump together with a simple controller, all 3 fitted on a robust baseplate, making it the ideal solution for many applications. With its one-gauge connection the TURBOLAB pumping station can be operated with either a TTR 91RN, TTR 101, PTR 90N, or PTR 225N vacuum gauge. Additionally, you can connect a venting valve with the turbomolecular pump. With the option gauge fitted, the controller can display gauge pressure or turbopump speed.

Condition: New



Product Number: P1013233



Price: $10,692.75


*Regular Price: $14,257.00



Leybold TURBOLAB 250 Benchtop Sys. CF100 CF 6 in. Inlet (no roughing pump) PN: 501592V09200000
In Stock: 2


Bench Top Model PN: 501592V09200000 (No Roughing Pump) This NEW Leybold TURBOLAB 250i benchtop vacuum pumping system comes with an CF100 CF 6 in. Inlet Flange and is a Full-Featured system at a basic system cost (WITH NO ROUGHING PUMP). The TURBOLAB 250i benchtop systems include a TURBOVAC 250i turbo pump, the TurboLab Pump System and frequency converter. The TURBOVACs are turbomolecular pumps with lifetime lubricated ceramic ball bearings. A built-in thermal switch switches off the TURBOVAC if the permissible temperature is exceeded. The frequency converter is integrated into the TURBOVAC and is supplied with 24 VDC and controlled via RS 485 interface by the TURBOLAB. They also are designed to mount further components such as Leybold vacuum gauges: TTR 101, TTR 91, PTR 91, TTR 101N, TTR 91N, PTR 91N. Two vacuum gauges can be operated simultaneously. They operate on 1-Phase, 100 or 240V power (correct voltage must be set on the unit).

Condition: New



Product Number: P1010074



Price: $8,363.25


*Regular Price: $11,151.00
