Inficon PSG550 Pirani Standard Gauge Tungsten Filament, mBar Measurement, DN 16 ISO-KF Fitting, D Sub 9 pin Connector, 2 set points Solid State, EtherCATŪ Interface, 1.2 - 8.5V Measurement Range.
Inficon Part Number: 3PI1-001-21G1.
This is a Inficon Pirani Standard Gauge PSG550. The Inficon Pirani Standard Gauge (PSG55x) employs the most advanced digital Pirani technology available. The rugged sensor design combined with the compact size and the variety of features qualifies as the right product for measurement from low to the high vacuum range. This Gauge has a D Sub 9 pin Connector and a 1.2 - 8.5V Measurement Range with 2 set points and EtherCAT Interface. This Gauge has a Pressure Measurement Range of 5x10-5 mbar (3.75X10-5 Torr) to 1000 mbar (750Torr).
This PSG550 Pirani Standard gauge can work with virtually any vacuum pump or vacuum pump system with the proper Inficon signal cable. This gauge has a D-Sub, 9-pin connector, EtherCAT interface.
NOTE: Since this gauge is configured for EtherCAT 1, it is not intended to be used with a controller.
For complete specifications of the Standard PSG550 gauge see the brochure .pdf, and for complete operation instructions see the instruction manual .pdf, both at the Downloads section.
