ISO-F DN 630 Bolt & Nut Set, for Smooth Thru Holes, Metric M12 x 80 mm Long Bolts, 1.75 mm Pitch, Stainless Steel, Quantity of 20

ISO-F DN 630 Bolt & Nut Set, for Smooth Thru Holes, Metric M12 x 80 mm Long Bolts, 1.75 mm Pitch, Stainless Steel, Quantity of 20.

These ISO-F DN 630 nut and bolt sets are for smooth hole flanges, for flange sizes of NW-630, and follow vacuum technology standards as described in DIN 28404 and ISO 1609. ISO-F fixed flange vacuum fittings have a bolt circle where bolts align the two flanges. A centering ring which contains a rubber elastomeric O-ring is used to form the vacuum seal between the two flange faces. They are commonly used to build process vacuum plumbing and systems for industrial vacuum applications. The ISO standard sizes for large LF flanges are ISO-F DN 63, 80, 100, 160, 200, 250, 320, 400, 500, 630. These vacuum fittings are made of corrosive resistant 304L stainless steel.

ISO-F 630 Bolt & Nut Set, for Smooth Hole NW-630 Vacuum Flanges, Stainless Steel, Quantity of 20
ISO-LF Flange Size: ISO-630F
Quantity: 20 Sets included with nuts and washers
Common Dimensions: Bolt Size M12 X 80 Long, Pitch 1.75 mm
Torque: to 7-10 lb-ft
