Edwards iM Serial Port PC Communications Module for iQDP, iH, & iL Semiconductor Vacuum Pumps.
Edwards Part Number: D372-32-000.
This iM serial port communications module allows you to use your computer to control the operation of and to monitor
the status of an iH, iL or iQ dry pumping system through the module's internal serial communication card via RS232 protocol. For example, you can connect the Communications Module to the serial port of a PC on which you have
installed a suitable SCADA (Supervisory Control And Data Acquisition program). All serial information sent to or received from the Communications Module is software derived; there is no direct electrical wiring to the sensors, pumps or valves in the dry pumping
system.
The communications module is connected to the Edwards iQDP, iH, or iL semiconductor vacuum pump system via an included 4 pin XLR cable (part number P108148). The module has a serial 9 pin DIN connector for connection to the control equipment (PLC or compuer). Use a serial to USB cable to connect to a system that doesn't have a serial port (part number P1010935).
Please download the available manual.
