Condition:
  New
Part Number:
  P107267
Warranty:
  Edwards Warranty

Available Now:
3  



$1,490.03


Print Version

Edwards Active Digital Pressure Controller ADC Enhanced MKII Version, D39591500


Edwards Active Digital Controller (ADC) Enhanced MKII Version.
Edwards Part Number D39591500

The Edwards Active Digital Controller (ADC) is a compact single line vacuum gauge controller and display, featuring a bright LED display and simple push-button controls. The ADC automatically recognizes compatible Edwards sensor gauges, loads the appropriate look-up table and displays the pressure in commonly used vacuum units. The ADC is available in standard and MKII Enhanced Versions. This is the MKII Enhanced Version. The ADC standard controller displays the pressure measured by a single active sensor gauge. On the other hand the ADC MKII enhanced controller now supports two different sensor gauges with two variable hysteresis set-points which are linked to 48 V dc 1A changeover relays and two 0-10 V dc analog outputs. To aid system integration the enhanced MKII enhanced controller is provided with an RS232 interface. When combined with suitable sensor gauges such as the Edwards APG100 Pirani, AIM Inverted Magnetron or Wide Range Gauge (WRG), both version ADC's represent a cost effective means of monitoring and controlling process vacuum in a broad range of applications. NOTE: This is not the Edwards TAG controller which looks very similar but controls Edwards Turbo Pumps and measures vacuum pressure. For detailed specifications and instructions for use on the ADC MKII Enhance Version Active Digital Controller, scroll down to AVAILABLE DOWNLOADS and download the Instruction Manual.pdf.

Features Include:
  • Wide Pressure Range Supports Edwards Active
    Gauges from 1500 to 7.5 x 10-10 Torr
  • Plug and Go operation, plug AC in, connect Edwards
    active gauge and ADC reads the vacuum pressure
  • Standard version reads 1 gauge, enhanced MKII version reads 2 gauges
  • High visibility display
  • Choice of display units, mbar, Torr, or Pascal
  • Compact instrument small 1/8 DIN enclosure
  • Simple to use


Press ESC to Close


PDF Logo Edwards Active Digital Controller ADC Instruction Manual.pdf

PDF Logo Edwards Pressure Gauge Product Catalog.pdf
