Condition:
  New
Part Number:
  P105017
Warranty:
  Against Product Defect

Available Now:
10  

RoHS Compliance Sticker


$203.27


Print Version

Buttweld 3-Way Reducing Tee Weld-On 2.0 to 6.0 Inch OD Tube Vacuum Fittings


Buttweld 3-Way Reducing Tee Weld-On 6.0 to 2.0 Inch OD Tube Vacuum Fittings,

These buttweld vacuum fittings are designed to be used in conjunctions with full line of ISO-Universal, ISO-KF and CF UHV Flanges, and are Easily welded to the flanges or each other during on-site installations. All components are made of type 304 stainless steel and are specifically prepared for use in high vacuum process or UHV applications.

Vacuum buttweld fittings are designed to be used in any vacuum applications where minimizing the number of sealed joints is critical.
  • Semiconductor wafer fabrication areas for remote installations and below a raised floor.
  • Permanent house vacuum vacuum lines
  • Vacuum utility lines for vacuum fixtures.
  • High temperature lines.
  • Burn box exhaust lines.
    Buttweld Reducing Tee Common Dimensions:
  • OD: 6.0" x 2.0"
  • Wall Thickness: 0.083" x 0.065" (2.11 mm x 1.65 mm)
  • A: 10.0 in (254.00 mm)
  • B: 5.0 in (127.00 mm)


Press ESC to Close


PDF Logo RoHS Compliance Download

CAD Picture

Ideal Spectroscopy offers 3D CAD models in Solidworks (SLDPRT), STP, & STEP formats. For those without CAD software a free trial 3D model viewer with measurement capabilities can be downloaded here:

E-drawing LogoeDrawings Viewer For Windows
E-drawing LogoeDrawings Viewer For MAC.
