Home > Bolt Kit for ISO-F DN 160 Gate Valve with Tapped Hole Flange, Includes 8 Silver Plated M10 x 1.50 x 25 mm Long Bolts and 8 Stainless Steel Washers.

Condition:

New

Part Number:

P1013156

Warranty:

Against Product Defect

Available Now: 37

RoHS Compliance Sticker

$19.54

Print Version

Bolt Kit for ISO-F DN 160 Gate Valve with Tapped Hole Flange, Includes 8 Silver Plated M10 x 1.50 x 25 mm Long Bolts and 8 Stainless Steel Washers.

ISO-F DN 160 Bolt Set, for Ideal Vacuum UltraLock Gate Valves Tapped Holes, Metric M10 x 25 mm Long Bolts, 1.50 mm Pitch, Silver-Plated, Quantity of 8 washers included.

These bolts are for tapped threaded hole flanges and follow ISO-LF standards for flange sizes of NW-160. ISO flanged vacuum fittings are commonly used to build process vacuum plumbing and systems for industrial applications. The fittings are quick to assemble using double claw clamps and a centering ring (please see top right figure - click to enlarge). The Viton® centering ring contains a rubber/elastomeric o-ring. The ISO standard sizes for large flanges are NW-63, NW-80, NW-100, NW-160, NW-200, NW-250, NW-320, NW-400, NW-500, NW-630. These vacuum fittings are made of corrosive resistant stainless steel.

Bolts, for Tapped Threaded Hole NW-160, Vacuum Flanges, Silver-Plated, Quantity of 8
ISO-LF Flange Size: NW-160
Quantity: 8 bolts include washers
Common Dimensions: Bolt Size M10 x 30 x 1.50mm Pitch

Press ESC to Close

Availability Of Kit Components Kit: P1013156 - Bolt Kit for ISO-F DN 160 Gate Valve with Tapped Hole Flange, Includes 8 Silver Plated M10 x 1.50 x 25 mm Long Bolts and 8 Stainless Steel Washers.
Component	Desc.	Req'd	Avail
Non-Standard	No Component Description Available On Website	8	296
Non-Standard	No Component Description Available On Website	8	452

RoHS Compliance Download
