These Agilent TwisTorr 305-FS turbo vacuum pump OEM package deals come with a 24-Volt DC power supply and are recommended to be used as replacement items in laboratory equipment or an already existing system. They include the following components:
- TwisTorr 305-FS Turbo with ISO-100 Inlet, Part number X3513-64008
- 24V DC On-Board Navigator Controller, Part number X3507-64130
- Air Cooling Kit for On-Board Controller, Part number X3500-68010
- Inlet Screen, Part number X3500-68000
- Power Cord, Part number 9699869
The Agilent Varian TwisTorr 305-FS turbomolecular vacuum pump, ISO 100K inlet, is a replacement for TwisTorr 304-FS Part Number X3500-64004. These Agilent Varian TwisTorr 305-FS turbomolecular high-vacuum pumps have new and improved performance over the previous 304FS turbo pumps. These improvements include a newer designed labyrinth Twistorr drag stage technology and the Agilent Floating Suspension (AFS) and now with optimized thermal design mapping. TwisTorr drag stages create high compression ratios for light gases such as Hydrogen and Helium to deliver high throughput and high tolerance of foreline pressure, thereby permitting the use of smaller and more economical backing pumps.
This technology results in a compact rotor design that is energy-efficient and maintains a low operating temperature. The Agilent Floating Suspension System (AFS) reduces noise and vibration, and ensures optimal bearing operating conditions to extend operating life, minimize system downtime, and assure stable pumping performance over long periods of time. The unique ceramic ball bearings with permanent lubrication eliminate oil and maintenance, and permit operation of the pump in any orientation. This model is the 305-FS and requires an outboard remote controller unit for operations. A 305-IC version is also available with a sleek onboard integrated controller built to the side of the pump.
Agilent turbo pumps are designed for optimum performance in real world applications and include integration of pumping systems and multi-flow pumps. Compact sized pumps meet the needs of industries with stringent space requirements. These new Agilent TwisTorr 305 FS turbo pumps require minimal to no maintenance and provide protection from misuse. These pumps go through a variety of qaulity and reliability tests to include: Long life, Shock, Vibration, Packaging, Thermal, Quiet and Noise. For a detailed explanation of these test see the brochure .pdf to the side at downloads.
The Agilent Varian TwistTorr 305-FS turbo pump with ISO-100K flange has a pumping speed of 255 l/s of nitrogen, KF-16 foreline flange and ambient operating temperature from 5 °C to +35 °C. These 305 FS pumps have a start up time of 3 minutes, Rotational speed 60,000 rpm. Recommend foreline pumps are dry IDP-3, IDP-7, IDP-10 or wet DS-102, DS-302. The cooling requirements are a minimum of forced air when conditions are 5- 35 °C ambient air temperature or water cooling with minimum flow: 50 l/h (0.22 GPM) with water temperature between +15 °C to +30 °C at a water pressure max of 5 bar (75 psi.) This unit is ambient air cooled but a water cooled unit is available.
These pumps can now use the New Vacuum Link App. availabe for Apple or Android smartphones, via Bluetooth, USB or NFC communications. This app allows for real-time monitoring of the parameters of your choice and offers recording capabilites, data export to your computer for display and sharing. The app can be downloaded off Agilents Website. For more technical information on the 305-FS download the brochure and operating instructions below.
The new Agilent TwisTorr 305-FS offers a blend of performance and features that is suited for a wide range of applications.
It is very versatile turbo and can be used in a variety of fields:
Typical Turbo Pump Applications include:
- Mass Spectrometry
- Gas Chromatography Mass Spectrometry (GC/MS)
- Liquid Chromatography Mass Spectrometry (LC/MS)
- Inductively Coupled Plasma Mass Spectrometry (ICP-MS)
- Time-of-Flight Mass Spectrometry (TOF)
Vacuum in Research and Development:
- High Energy Physics
- Fusion Technology
- General UHV Research
- Synchrotron Light Sources Particle Accelerators
Nanotechnology Instruments:
- Electron Microscopy
- Scanning Electron Microscopy (SEM)
- Transmission Electron Microscopy (TEM)
- Focused Ion-beam Systems (FIB)
- Surface Analysis
- Semiconductor Manufacturing
Industrial Vacuum Processing:
- Thin Film Deposition:
- Glass coating equipment (architectural and automotive glass, flat panel displays)
- Thin film solar cells production (photo-voltaic)
- Optical data media (CD, DVD, Magneto Optical Discs)
- Magnetic storage media
- Surface treatments
- Optical coating (ophthalmic, precision opto-electronics)
- Roll/Web coating on films or foils
- Device Processing:
- TV & Monitor picture tube manufacture
- Evacuation of lamps (motorway lighting, beamers)
- X-Ray tubes & electron devices
- General Processes:
- Vacuum Furnaces
- Metallurgy
Please see below our Related section for accessories that may benefit your vacuum applications and needs. We offer a large variety of vacuum fittings, hoses, vacuum gauges, sensors/transducers and accessories sold separately on this website. Call us for a quote (505) 872-0037.
For instruction manuals, please see the downloads below.
